BUILT FOR THE DEMANDS OF THE AGRICULTURE MARKET
Flint Power Systems Agricultural Gensets are designed and built with your need in mind, powered by the John Deere engines you know and trust. THINK FLINT FIRST.
YOUR OPERATION DOESN’T HAVE TO STOP, EVEN IF THE POWER DOES.
Let Flint protect you with our comprehensive line of emergency stationary generators.
Flint Agricultural Gensets are designed and engineered to keep your operation running no matter what happens to the grid. Our gensets are designed and built with the best, most durable components so you can rely on your generator for years to come. The standard skid-mounted units have all the features you need to keep your operation running, at a very affordable price. A comprehensive set of options are available, so you can customize your genset to meet your exact needs and standards.Standard Features:
* Heavy-duty John Deere diesel engine* Marathon® 4-wire alternator, 120/240V 1 phase
* Deep Sea® 4510 Digital control panel with auto-start
* Engine block heater
* Battery rack and cables
* Oil and coolant filled
* Narrow base for ease of installation
* Industrial grade silencer with raincap
Optional Upgrades:
* Marathon® 12-wire alternator, 3 phase (208V, 240V or 480V)* Marelli® alternators, 4 wire single phase or 12 wire 3 phase
* Deep Sea® Premium 7310 control panel
* Main Line Circuit Breaker integrated into alternator housing
* Engine starting batteries
* Battery charger
* Battery maintainer
* Emergency-stop button
* Heavy-duty canister-style air cleaner
* Above ground “ag style” fuel tank
* Sub-base fuel tank, UL 142 listed
* Weatherproof powder-coated Galvanneal enclosure with roof-mounted silencer and raincap
*Automatic transfer switches
* Custom engineered solutions
*All emergency stationary genset engines are Tier 3 emissions.
Design and/or specification of Flint Agricultural Gensets may change at any time without any notice.
Design and/or specification of Flint Agricultural Gensets may change at any time without any notice.
ABOUT FLINT POWER SYSTEMS AGRICULTURAL GENSETS
Flint Agricultural Gensets are designed and built-in Albany, GA by Flint Power Systems, the authorized John Deere Power Systems Distributor for the Southeastern US. Flint Power Systems has over 30 years of experience designing and building generator sets, irrigation power units, and engine-driven solutions for John Deere dealers and Industrial OEMs. These Agricultural Gensets are available through John Deere Dealers and are backed by the same John Deere support that you have trusted for generations. Every FPS Agricultural Genset is supplied with a one-year, unlimited hours warranty. Certain components of the genset package are backed by the manufacturer’s warranty of the specific component and may extend beyond the 1 year full package warranty.
www.flintequipco.com
JOHN DEERE POWERTECH GENERATOR DRIVE ENGINE
John Deere PowerTech engines are the ultimate in performance, fuel economy and emissions compliance. They are the best choice for all generator applications. Features include:* EPA Tier 3 emissions for Emergency Standby (stationary) applications. No after-treatment
* Best in class fuel economy
* Legendary John Deere durability and reliability
* Turbo-charging technology provides exceptional load acceptance and block loading capability
* Electronic engines provide improved control and performance
* Heavy-duty, oversized components and wet-type cylinder liners provide long engine life
MARATHON MagnaPLUS GENERATOR
The MagnaPLUS is the ideal generator for agriculture applications. Features include:* 120/240 VAC, 4 lead, dedicated single phase, 60 Hz output
* 1800 RPM operation, 40 degrees Celsius Ambient temperature rating
* Voltage regulator provides 1% regulation and under-speed protection
* Rugged construction with solid-state technology
OPTIONAL UPGRADES ADD ADDITIONAL FEATURES:
* 12 Wire reconnect-able leads for manual voltage change
* 3 Phase output at 120/208, 120/240 or 277/480
* Permanent magnet generator
* Integrated mainline circuit breaker
DEEP SEA DIGITAL GENERATOR CONTROL PANEL
The DSE4510 Auto Start Control Panel provides an outstanding range of features:
* Alternator frequency & CAN speed sensing
* Real-time clock provides accurate event logging
* 3 phase generator sensing (if applicable)
* Generator/load power monitoring (kW, kVa, kVa-r, pf)
* Generator overload protection (kW)
* Comprehensive warning, electrical trip or shutdown protection upon fault condition
* Engine run-time scheduler, idle control, pre-heat and speed protection
* Battery voltage monitoring
OPTIONAL UPGRADE TO DSE7310 ADDS ADDITIONAL FEATURES:
* Advanced display and menu navigation
* Customizable status screens
* Configurable timers and alarms
* Multiple date and time scheduler
* 3x more configurable inputs and outputs
* Alternator frequency & CAN speed sensing
* Real-time clock provides accurate event logging
* 3 phase generator sensing (if applicable)
* Generator/load power monitoring (kW, kVa, kVa-r, pf)
* Generator overload protection (kW)
* Comprehensive warning, electrical trip or shutdown protection upon fault condition
* Engine run-time scheduler, idle control, pre-heat and speed protection
* Battery voltage monitoring
OPTIONAL UPGRADE TO DSE7310 ADDS ADDITIONAL FEATURES:
* Advanced display and menu navigation
* Customizable status screens
* Configurable timers and alarms
* Multiple date and time scheduler
* 3x more configurable inputs and outputs
